C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 100 –
MAIN MENU Using the onboard web agent, you can define system parameters, manage
and control the switch, and all its ports, or monitor network conditions. The
following table briefly describes the selections available from this program.
Table 6: Switch Main Menu
Menu Description Page
System
General Provides basic system description, including contact information 117
Switch Shows the number of ports, hardware version, power status, and
firmware version numbers
118
IP Sets IPv4 address for management interface and gateway 566
Configure Global Sets IP address of the gateway router between this device and
management stations that exist on other network segments
566
Configure Interface Configures IP address for management access 567
Add Address Sets the IPv4 address for management access 567
Show Address Shows the IPv4 address for management access 567
Capability Enables support for jumbo frames;
shows the bridge extension parameters
120,
121
File 122
Copy Allows the transfer and copying files 122
Set Startup Sets the startup file 125
Show Shows the files stored in flash memory; allows deletion of files 126
Automatic Operation Code Upgrade Automatically upgrades operation code if a newer version is
found on the server
127
Time 131
Configure General
Manual Manually sets the current time 131
SNTP Configures SNTP polling interval 132
NTP Configures NTP authentication parameters 133
Configure Time Server Configures a list of SNTP servers 134
Configure SNTP Server Sets the IP address for SNTP time servers 134
Add NTP Server Adds NTP time server and index of authentication key 135
Show NTP Server Shows list of configured NTP time servers 135
Add NTP Authentication Key Adds key index and corresponding MD5 key 136
Show NTP Authentication Key Shows list of configured authentication keys 136
Configure Time Zone Sets the local time zone for the system clock 138
Console Sets console port connection parameters 139
Telnet Sets Telnet connection parameters 140
CPU Utilization Displays information on CPU utilization 142
Memory Status Shows memory utilization parameters 143
Reset Restarts the switch immediately, at a specified time, after a
specified delay, or at a periodic interval
144
