C
HAPTER
25
| General Security Measures
Network Access (MAC Address Authentication)
– 881 –
regardless of the 802.1X Operation Mode (Single-Host, Multi-Host, or
MAC-Based authentication as described on page 852).
â—† The maximum number of secure MAC addresses supported for the
switch system is 1024.
EXAMPLE
Console(config-if)#network-access aging
Console(config-if)#
network-access
mac-filter
Use this command to add a MAC address into a filter table. Use the no
form of this command to remove the specified MAC address.
SYNTAX
[no] network-access mac-filter filter-id
mac-address mac-address [mask mask-address]
filter-id - Specifies a MAC address filter table. (Range: 1-64)
mac-address - Specifies a MAC address entry.
(Format: xx-xx-xx-xx-xx-xx)
mask - Specifies a MAC address bit mask for a range of addresses.
DEFAULT SETTING
Disabled
COMMAND MODE
Global Configuration
COMMAND USAGE
â—† Specified addresses are exempt from network access authentication.
â—† This command is different from configuring static addresses with the
mac-address-table static command in that it allows you configure a
range of addresses when using a mask, and then to assign these
addresses to one or more ports with the network-access port-mac-filter
command.
â—† Up to 64 filter tables can be defined.
â—† There is no limitation on the number of entries that can entered in a
filter table.
EXAMPLE
Console(config)#network-access mac-filter 1 mac-address 11-22-33-44-55-66
Console(config)#
