C
HAPTER
39
| Multicast Filtering Commands
MVR for IPv6
– 1289 –
show mvr6 This command shows information about MVR domain settings, including
MVR operational status, the multicast VLAN, the current number of group
addresses, and the upstream source IP address.
SYNTAX
show mvr6 [domain domain-id]
domain-id - An independent multicast domain. (Range: 1-5)
DEFAULT SETTING
Displays configuration settings for all MVR domains.
COMMAND MODE
Privileged Exec
EXAMPLE
The following shows the MVR settings:
Console#show mvr6
MVR6 802.1p Forwarding Priority: Disabled
MVR6 Proxy Switching : Enabled
MVR6 Robustness Value : 2
MVR6 Proxy Query Interval : 125(sec.)
MVR6 Source Port Mode : Always Forward
Domain : 1
MVR6 Config Status : Enabled
MVR6 Running Status : Active
MVR6 Multicast VLAN : 1
MVR6 Current Learned Groups : 0
MVR6 Upstream Source IP : FF05::25
Console#
Table 170: show mvr6 - display description
Field Description
MVR6 802.1p
Forwarding Priority
Priority assigned to multicast traffic forwarded into the MVR6 VLAN
MVR Proxy Switching Shows if MVR proxy switching is enabled
MVR Robustness Value Shows the number of reports or query messages sent when proxy
switching is enabled
MVR6 Proxy Query
Interval
The interval at which the receiver port sends out general queries
MVR6 Source Port
Mode
Shows if the switch only forwards multicast streams which the
source port has dynamically joined or always forwards multicast
streams
MVR6 Domain An independent multicast domain.
MVR6 Config Status Shows if MVR is globally enabled on the switch.
MVR6 Running Status Indicates whether or not all necessary conditions in the MVR
environment are satisfied. (Running status is true as long as MVR
Status is enabled, and the specified MVR VLAN exists, and a source
port with a valid link has been configured (using the mvr6 type
command.)
