C
HAPTER
17
| Multicast Filtering
Multicast VLAN Registration for IPv6
– 671 –
◆ VLAN – The VLAN through which the service is received. Note that this
may be different from the MVR6 VLAN if the group address has been
statically assigned.
◆ Port – Indicates the source address of the multicast service, or
displays an asterisk if the group address has been statically assigned
(these entries are marked as “Source”). Also shows the interfaces with
subscribers for multicast services provided through the MVR6 VLAN
(these entries are marked as “Receiver”).
◆ Up Time – Time this service has been forwarded to attached clients.
◆ Expire – Time before this entry expires if no membership report is
received from currently active or new clients.
◆ Count – The number of multicast services currently being forwarded
from the MVR6 VLAN.
WEB INTERFACE
To display the interfaces assigned to the MVR6 receiver groups:
1. Click Multicast, MVR6.
2. Select Show Member from the Step list.
3. Select an MVR6 domain.
Figure 409: Displaying MVR6 Receiver Groups
DISPLAYING
MVR6 STATISTICS
Use the Multicast > MVR6 > Show Statistics pages to display MVR6
protocol-related statistics for the specified interface.
CLI REFERENCES
◆ "show mvr6 statistics" on page 1293
PARAMETERS
These parameters are displayed:
◆ Domain ID – An independent multicast domain. (Range: 1-5)
◆ VLAN – VLAN identifier. (Range: 1-4094)
