C
HAPTER
16
| IP Services
Configuring the PPPoE Intermediate Agent
– 600 –
◆ Server IP Address – Addresses of DHCP servers or relay servers to be
used by the switch’s DHCP relay agent in order of preference.
WEB INTERFACE
To configure DHCP relay service:
1. Click IP Service, DHCP, Relay Option 82.
2. Enable or disable Option 82.
3. Set the Option 82 policy to specify how to handle Option 82 information
already contained in DHCP client request packets.
4. Specify whether or not include “type” and “length” sub-options.
5. Set the frame format used for the remote ID.
6. Enter up to five IP addresses for DHCP servers or relay servers in order
of preference.
7. Click Apply.
Figure 353: Configuring DHCP Relay Information Option 82 Service
CONFIGURING THE PPPOE INTERMEDIATE AGENT
This section describes how to configure the PPPoE Intermediate Agent
(PPPoE IA) relay parameters required for passing authentication messages
between a client and broadband remote access servers.
CONFIGURING PPPOE
IA GLOBAL SETTINGS
Use the IP Service > PPPoE Intermediate Agent (Configure Global) page to
enable the PPPoE IA on the switch, set the access node identifier, and set
the generic error message.
CLI REFERENCES
◆ "pppoe intermediate-agent" on page 865
◆ "pppoe intermediate-agent port-format-type" on page 867
