| Using the Web Interface
Navigating the Web Browser Interface
– 101 –
Interface 149
Port 150
General
Configure by Port List Configures connection settings per port 150
Configure by Port Range Configures connection settings for a range of ports 152
Show Information Displays port connection status 153
Mirror 154
Add Sets the source and target ports for mirroring 154
Show Shows the configured mirror sessions 154
Statistics Shows Interface, Etherlike, and RMON port statistics 160
Chart Shows Interface, Etherlike, and RMON port statistics 160
Transceiver Shows identifying information and operational parameters for
optical transceivers which support Digital Diagnostic Monitoring
(DDM), and configures thresholds for alarm and warning
messages for optical transceivers which support DDM
164,
165
Cable Test Performs cable diagnostics for selected port to diagnose any cable
faults (short, open etc.) and report the cable length
168
Trunk
Static 171
Configure Trunk 171
Add Creates a trunk, along with the first port member 171
Show Shows the configured trunk identifiers 171
Add Member Specifies ports to group into static trunks 171
Show Member Shows the port members for the selected trunk 171
Configure General 171
Configure Configures trunk connection settings 171
Show Information Displays trunk connection settings 171
Dynamic 173
Configure Aggregator Configures administration key for specific LACP groups 173
Configure Aggregation Port 171
Configure 171
General Allows ports to dynamically join trunks 173
Actor Configures parameters for link aggregation group members on the
local side
173
Partner Configures parameters for link aggregation group members on the
remote side
173
Show Information 179
Counters Displays statistics for LACP protocol messages 179
Internal Displays configuration settings and operational state for the local
side of a link aggregation
180
