C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 102 –
Neighbors Displays configuration settings and operational state for the
remote side of a link aggregation
182
Configure Trunk 173
Configure Configures connection settings 173
Show Displays port connection status 173
Show Member Shows the active members in a trunk 173
Statistics Shows Interface, Etherlike, and RMON port statistics 160
Chart Shows Interface, Etherlike, and RMON port statistics 160
Load Balance Sets the load-distribution method among ports in aggregated links 183
Green Ethernet Adjusts the power provided to ports based on the length of the
cable used to connect to other devices
185
RSPAN Mirrors traffic from remote switches for analysis at a destination
port on the local switch
156
VLAN Trunking Allows unknown VLAN groups to pass through the specified
interface
190
VLAN Virtual LAN 193
Static
Add Creates VLAN groups 196
Show Displays configured VLAN groups 196
Modify Configures group name and administrative status 196
Edit Member by VLAN Specifies VLAN attributes per VLAN 198
Edit Member by Interface Specifies VLAN attributes per interface 198
Edit Member by Interface Range Specifies VLAN attributes per interface range 198
Dynamic
Configure General Enables GVRP VLAN registration protocol globally 203
Configure Interface Configures GVRP status and timers per interface 203
Show Dynamic VLAN 203
Show VLAN Shows the VLANs this switch has joined through GVRP 203
Show VLAN Member Shows the interfaces assigned to a VLAN through GVRP 203
Tunnel IEEE 802.1Q (QinQ) Tunneling 206
Configure Global Sets tunnel mode for the switch 210
Configure Service Sets a CVLAN to SPVLAN mapping entry 211
Configure Interface Sets the tunnel mode for any participating interface 213
Protocol 214
Configure Protocol 215
Add Creates a protocol group, specifying supported protocols 215
Show Shows configured protocol groups 215
Table 6: Switch Main Menu (Continued)
Menu Description Page
