PowerPC e500 Core Family Reference Manual, Rev. 1
3-30 Freescale Semiconductor
Instruction Model
3.3.1.6 Memory Synchronization Instructions
Memory synchronization instructions control the order in which memory operations complete
with respect to asynchronous events and the order in which memory operations are seen by other
mechanisms that access memory. See Section 3.3.1.7, “Atomic Update Primitives Using lwarx
and stwcx.,” for additional information about these instructions and about related aspects of
memory synchronization. See Table 3-25 for a summary.
Table 3-25. Memory Synchronization Instructions
Name Mnemonic Syntax Implementation Notes
Instruction
Synchronize
isync — isync is refetch serializing; the e500 waits for previous instructions (including any interrupts
they generate) to complete before isync executes, which purges all instructions from the
core and refetches the next instruction. isync does not wait for pending stores in the store
queue to complete. Any subsequent instruction sees all effects of instructions before the
isync.
Because it prevents execution of subsequent instructions until preceding instructions
complete, if an isync follows a conditional branch instruction that depends on the value
returned by a preceding load, the load on which the branch depends is performed before
any loads caused by instructions after the isync even if the effects of the dependency are
independent of the value loaded (for example, the value is compared to itself and the
branch tests selected, CR
n
[EQ]), and even if the branch target is the next sequential
instruction to be executed.
Load Word
and
Reserve
Indexed
lwarx rD,rA,rB lwarx with stwcx. can emulate semaphore operations such as test and set, compare and
swap, exchange memory, and fetch and add. Both instructions must use the same EA.
Reservation granularity is implementation-dependent. The e500 makes reservations on
behalf of aligned 32-byte sections of address space. Executing lwarx and stwcx. to a page
marked write-through (WIMG = 10
xx
) or when the data cache is locked causes a data
storage interrupt. If the location is not word-aligned, an alignment interrupt occurs.
See Section 3.3.1.7, “Atomic Update Primitives Using lwarx and stwcx.”
Memory
Barrier
mbar MO mbar provides a memory barrier. (Note that mbar uses the same opcode as eieio, defined
by the Classic PowerPC architecture, and with which mbar (MO=1) is identical, as defined
by the EIS). The behavior of mbar depends on the value of MO operand.
MO ≠ 0—mbar instruction provides a storage ordering function for all memory access
instructions executed by the processor executing mbar. Executing mbar ensures that all
data storage accesses caused by instructions preceding the mbar have completed before
any data storage accesses caused by any instructions after the mbar. This order is seen
by all mechanisms.
MO = 1—The EIS defines mbar to function identically to eieio, as defined by the classic
PowerPC architecture. For more information, see Section 3.3.1.6.1, “mbar (MO = 1).”
The following sequence shows one use of mbar in supporting shared data, ensuring the
action is completed before the lock is released.
P1 P2
lock . . .
read & write . . .
mbar . . .
free lock . . .
. . . lock
. . . read & write
. . . mbar
. . . free lock
