Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-2 Freescale Semiconductor
addo
011111 rD rA rB 11000010100
X addo
addo.
011111 rD rA rB 11000010101
X addo.
addze
011111 rD rA /// 00110010100
X addze
addze.
011111 rD rA /// 00110010101
X addze.
addzeo
011111 rD rA /// 10110010100
X addzeo
addzeo.
011111 rD rA /// 10110010101
X addzeo.
and
011111 rS rA rB 00000111000
X and
and.
011111 rS rA rB 00000111001
X and.
andc
011111 rS rA rB 00001111000
X andc
andc.
011111 rS rA rB 00001111001
X andc.
andi.
011100 rS rA UIMM
D andi.
andis.
011101 rS rA UIMM
D andis.
b
010010 LI 0 0
I b
ba
010010 LI 1 0
I ba
bbelr
011111 /// 10001001100
X bbelr
bblels
011111 /// 10001001100
X bblels
bc
010000 BO BI BD 0 0
B bc
bca
010000 BO BI BD 1 0
B bca
bcctr
010011 BO BI /// 10000100000
XL bcctr
bcctrl
010011 BO BI /// 10000100001
XL bcctrl
bcl
010000 BO BI BD 0 1
B bcl
bcla
010000 BO BI BD 1 1
B bcla
bclr
010011 BO BI /// 00000100000
XL bclr
bclrl
010011 BO BI /// 00000100001
XL bclrl
bctr bctr
1
equivalent to bcctr 20,0 bctr
bctrl bctrl
1
equivalent to bcctrl 20,0 bctrl
bdnz bdnz target
1
equivalent to bc 16,0,target bdnz
bdnza bdnza target
1
equivalent to bca 16,0,target bdnza
bdnzf bdnzf BI,target equivalent to bc 0,BI,target bdnzf
bdnzfa bdnzfa BI,target equivalent to bca 0,BI,target bdnzfa
bdnzfl bdnzfl BI,target
equivalent to bcl 0,BI,target bdnzfl
bdnzfla bdnzfla BI,target equivalent to bcla 0,BI,target bdnzfla
bdnzflr bdnzflr BI equivalent to bclr 0,BI bdnzflr
Table D-1. Instructions (Binary) by Mnemonic
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
