Freescale Semiconductor PowerPC e500 Core - Page 510

Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-30 Freescale Semiconductor
rlwimi.
20 (0x14) rS rA SH MB ME Rc
M rlwimi.
rlwinm
21 (0x15) rS rA SH MB ME 0
M rlwinm
rlwinm.
21 (0x15) rS rA SH MB ME 1
M rlwinm.
rlwnm
23 (0x17) rS rA rB MB ME Rc
M rlwnm
rlwnm.
23 (0x17) rS rA rB MB ME Rc
M rlwnm.
ori
24 (0x18) rS rA UIMM
D ori
oris
25 (0x19) rS rA UIMM
D oris
xori
26 (0x1A) rS rA UIMM
D xori
xoris
27 (0x1B) rS rA UIMM
D xoris
andi.
28 (0x1C) rS rA UIMM
D andi.
andis.
29 (0x1D) rS rA UIMM
D andis.
add
31 (0x1F) rD rA rB 01000010100
X add
add.
31 (0x1F) rD rA rB 01000010101
X add.
addc
31 (0x1F) rD rA rB 00000010100
X addc
addc.
31 (0x1F) rD rA rB 00000010101
X addc.
addco
31 (0x1F) rD rA rB 10000010100
X addco
addco.
31 (0x1F) rD rA rB 10000010101
X addco.
adde
31 (0x1F) rD rA rB 00100010100
X adde
adde.
31 (0x1F) rD rA rB 00100010101
X adde.
addeo
31 (0x1F) rD rA rB 10100010100
X addeo
addeo.
31 (0x1F) rD rA rB 10100010101
X addeo.
addme
31 (0x1F) rD rA /// 00111010100
X addme
addme.
31 (0x1F) rD rA /// 00111010101
X addme.
addmeo
31 (0x1F) rD rA /// 10111010100
X addmeo
addmeo.
31 (0x1F) rD rA /// 10111010101
X addmeo.
addo
31 (0x1F) rD rA rB 11000010100
X addo
addo.
31 (0x1F) rD rA rB 11000010101
X addo.
addze
31 (0x1F) rD rA /// 00110010100
X addze
addze.
31 (0x1F) rD rA /// 00110010101
X addze.
addzeo
31 (0x1F) rD rA /// 10110010100
X addzeo
addzeo.
31 (0x1F) rD rA /// 10110010101
X addzeo.
and
31 (0x1F) rS rA rB 00000111000
X and
and.
31 (0x1F) rS rA rB 00000111001
X and.
Table D-2. Instructions (Decimal and Hexadecimal) by Opcode
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
