Opcode Listings

PowerPC e500 Core Family Reference Manual, Rev. 1

D-36 Freescale Semiconductor

addo

011111 rD rA rB 11000010100

X addo

addo.

011111 rD rA rB 11000010101

X addo.

addze

011111 rD rA /// 00110010100

X addze

addze.

011111 rD rA /// 00110010101

X addze.

addzeo

011111 rD rA /// 10110010100

X addzeo

addzeo.

011111 rD rA /// 10110010101

X addzeo.

and

011111 rS rA rB 00000111000

X and

and.

011111 rS rA rB 00000111001

X and.

andc

011111 rS rA rB 00001111000

X andc

andc.

011111 rS rA rB 00001111001

X andc.

bbelr

011111 /// 10001001100

X bbelr

bblels

011111 /// 10001001100

X bblels

cmp

011111 crfD / L rA rB 0000000000 /

X cmp

cmpl

011111 crfD / L rA rB 0000100000 /

X cmpl

cntlzw

011111 rS rA /// 00000110100

X cntlzw

cntlzw.

011111 rS rA /// 00000110101

X cntlzw.

dcba

011111 /// rA rB 1011110110 /

X dcba

dcbf

011111 /// rA rB 0001010110 /

X dcbf

dcbi

011111 /// rA rB 0111010110 /

X dcbi

dcblc

011111 CT rA rB 01100001100

X dcblc

dcbst

011111 /// rA rB 0000110110 /

X dcbst

dcbt

011111 CT rA rB 0100010110 /

X dcbt

dcbtls

011111 CT rA rB 00101001100

X dcbtls

dcbtst

011111 CT rA rB 0011110110 /

X dcbtst

dcbtstls

011111 CT rA rB 00100001100

X dcbtstls

dcbz

011111 /// rA rB 1111110110 /

X dcbz

divw

011111 rD rA rB 01111010110

X divw

divw.

011111 rD rA rB 01111010111

X divw.

divwo

011111 rD rA rB 11111010110

X divwo

divwo.

011111 rD rA rB 11111010111

X divwo.

divwu

011111 rD rA rB 01110010110

X divwu

divwu.

011111 rD rA rB 01110010111

X divwu.

divwuo

011111 rD rA rB 11110010110

X divwuo

Table D-3. Instructions (Binary) by Form

Mnemonic

012345678910111213141516171819202122232425262728293031

Form Mnemonic
