Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-38 Freescale Semiconductor
mullw
011111 rD rA rB 00111010110
X mullw
mullw.
011111 rD rA rB 00111010111
X mullw.
mullwo
011111 rD rA rB 10111010110
X mullwo
mullwo.
011111 rD rA rB 10111010111
X mullwo.
nand
011111 rS rA rB 01110111000
X nand
nand.
011111 rS rA rB 01110111001
X nand.
neg
011111 rD rA /// 00011010000
X neg
neg.
011111 rD rA /// 00011010001
X neg.
nego
011111 rD rA /// 10011010000
X nego
nego.
011111 rD rA /// 10011010001
X nego.
nor
011111 rS rA rB 00011111000
X nor
nor.
011111 rS rA rB 00011111001
X nor.
or
011111 rS rA rB 01101111000
X or
or.
011111 rS rA rB 01101111001
X or.
orc
011111 rS rA rB 01100111000
X orc
orc.
011111 rS rA rB 01100111001
X orc.
slw
011111 rS rA rB 00000110000
X slw
slw.
011111 rS rA rB 00000110001
X slw.
sraw
011111 rS rA rB 11000110000
X sraw
sraw.
011111 rS rA rB 11000110001
X sraw.
srawi
011111 rS rA SH 11001110000
X srawi
srawi.
011111 rS rA SH 11001110001
X srawi.
srw
011111 rS rA rB 10000110000
X srw
srw.
011111 rS rA rB 10000110001
X srw.
stbux
011111 rS rA rB 00111101110
X stbux
stbx
011111 rS rA rB 00110101110
X stbx
sthbrx
011111 rS rA rB 1110010110 /
X sthbrx
sthux
011111 rS rA rB 0110110111 /
X sthux
sthx
011111 rS rA rB 0110010111 /
X sthx
stwbrx
011111 rS rA rB 1010010110 /
X stwbrx
stwcx.
011111 rS rA rB 00100101101
X stwcx.
subf
011111 rD rA rB 00001010000
X subf
subf.
011111 rD rA rB 00001010001
X subf.
Table D-3. Instructions (Binary) by Form
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
