PowerPC e500 Core Family Reference Manual, Rev. 1
2-6 Freescale Semiconductor
Register Model
Table 2-1. Book E Special-Purpose Registers (by SPR Abbreviation)
SPR
Abbreviation
Name
Defined SPR Number
Access
Supervisor
Only
Section/
Page
Decimal Binary
ATBL Alternate time base register lower 526 10000 01110 Read-only No 2.6.6/2-16
ATBU Alternate time base register upper 527 10000 01111 Read-only No 2.6.6/2-16
CSRR0 Critical save/restore register 0 58 00001 11010 Read/Write Yes 2.7.1.1/2-18
CSRR1 Critical save/restore register 1 59 00001 11011 Read/Write Yes 2.7.1.1/2-18
CTR Count register 9 00000 01001 Read/Write No 2.4.3/2-10
DAC1 Data address compare 1 316 01001 11100 Read/Write Yes 2.13.4/2-48
DAC2 Data address compare 2 317 01001 11101 Read/Write Yes 2.13.4/2-48
DBCR0 Debug control register 0
1
308 01001 10100 Read/Write Yes 2.13.1/2-46
DBCR1 Debug control register 1
1
309 01001 10101 Read/Write Yes 2.13.1/2-46
DBCR2 Debug control register 2
1
310 01001 10110 Read/Write Yes 2.13.1/2-46
DBSR Debug status register 304 01001 10000 Read/Clear
2
Ye s 2.13.2/2-47
DEAR Data exception address register 61 00001 11101 Read/Write Yes 2.6.5/2-16
DEC Decrementer 22 00000 10110 Read/Write Yes 2.6.4/2-16
DECAR Decrementer auto-reload 54 00001 10110 Write-only Yes 2.6.4/2-16
ESR Exception syndrome register 62 00001 11110 Read/Write Yes 2.7.1.6/2-20
IAC1 Instruction address compare 1 312 01001 11000 Read/Write Yes 2.13.3/2-48
IAC2 Instruction address compare 2 313 01001 11001 Read/Write Yes 2.13.3/2-48
IVOR0 Critical input 400 01100 10000 Read/Write Yes 2.7.1.5/2-19
IVOR1 Machine check interrupt offset 401 01100 10001 Read/Write Yes 2.7.1.5/2-19
IVOR2 Data storage interrupt offset 402 01100 10010 Read/Write Yes 2.7.1.5/2-19
IVOR3 Instruction storage interrupt offset 403 01100 10011 Read/Write Yes 2.7.1.5/2-19
IVOR4 External input interrupt offset 404 01100 10100 Read/Write Yes 2.7.1.5/2-19
IVOR5 Alignment interrupt offset 405 01100 10101 Read/Write Yes 2.7.1.5/2-19
IVOR6 Program interrupt offset 406 01100 10110 Read/Write Yes 2.7.1.5/2-19
IVOR8 System call interrupt offset 408 01100 11000 Read/Write Yes 2.7.1.5/2-19
IVOR10 Decrementer interrupt offset 410 01100 11010 Read/Write Yes 2.7.1.5/2-19
IVOR11 Fixed-interval timer interrupt offset 411 01100 11011 Read/Write Yes 2.7.1.5/2-19
IVOR12 Watchdog timer interrupt offset 412 01100 11100 Read/Write Yes 2.7.1.5/2-19
IVOR13 Data TLB error interrupt offset 413 01100 11101 Read/Write Yes 2.7.1.5/2-19
IVOR14 Instruction TLB error interrupt offset 414 01100 11110 Read/Write Yes 2.7.1.5/2-19
IVOR15 Debug interrupt offset 415 01100 11111 Read/Write Yes 2.7.1.5/2-19
IVPR Interrupt vector 63 00001 11111 Read/Write Yes 2.7.1.4/2-19
LR Link register 8 00000 01000 Read/Write No 2.4.2/2-10
