Example: Registering Constant (Character) for receive command data
When the trigger condition is satisfied, the received data is compared with the registered data, and the value of the
Index No. 2 of the matching data is stored in Index Device LDR100.
Item Setting
Number of Registering Constants 3
Registering Constants
Index No. 1: 123
Index No. 2: 456
Index No. 3: 789
Index Device LDR100
Received data
Compare
4
(34h)
5
(35h)
6
(36h)
Order of reception
2LDR100:
Value of the Index Device
1231:
4562:
7893:
DataIndex No.
Number of
Registering
Constants: 3
(DEC)
