IDEC SmartAXIS Touch FT1A Series User Manual

SmartAXIS Touch User’s Manual 25-3
1 Project Transfer Function
25
Data Transfer Function
5 Specify the drive for the USB flash drive, and then click OK.
A continue download confirmation message is displayed.
■ Drive
Specify the drive assigned to the external memory.
■ Network
Displays the Network Drive Assignment dialog box. You can specify a drive on the network.
■ External Memory Folder
Specify the folder where the project data is to be downloaded.
Click to display the Project Settings dialog box. You can specify an External Memory Folder as the download
destination.
6 Click Yes.
The Download dialog box is displayed and the project data is now being saved.
When this process is complete, a message is displayed.
7 Click OK.

IDEC SmartAXIS Touch FT1A Series Specifications

General

Brand	IDEC
Model	SmartAXIS Touch FT1A Series
Category	Controller
Language	English
