SmartAXIS Touch User's Manual 27-15
2 Word Devices
27
Internal Devices
D8056 High-Speed Counter (Group 2/I2)
These special data registers are
used with the high-speed counter
function and the frequency
measurement function.
For details, refer to Chapter 3 “4.7
High-Speed Counter” on page 3-55.
Upper Word
Current Value / Frequency
Measurement Value (I2)
Every scan YES YES
D8057 Lower Word
D8058 Upper Word
Preset Value YES YES
D8059 Lower Word
D8060 Upper Word
Reset Value YES YES
D8061 Lower Word
D8062 to
8067
Reserved
D8068 High-Speed Counter (Group 3/I3)
These special data registers are
used with the high-speed counter
function and the frequency
measurement function.
For details, refer to Chapter 3 “4.7
High-Speed Counter” on page 3-55.
Upper Word
Current Value / Frequency
Measurement Value (I3)
Every scan YES YES
D8069 Lower Word
D8070 Upper Word
Preset Value YES YES
D8071 Lower Word
D8072 Upper Word
Reset Value YES YES
D8073 Lower Word
D8074 to
8076
Reserved
D8077
Out of Analog Input Range Status
If the analog input signal exceeds 11 V or 21 mA, the corresponding bits of
D8077 (bit 0, 1) become 1. If the signal falls below 11 V or 21 mA, the bits
become 0.
If the analog input signal falls below 2 mA, the corresponding bits of D8077 (bit
2, 3) become 1. If the signal exceeds 2 mA, the bits become 0.
The assignment of each analog input is as follows.
YES YES
D8078 to
8109
Reserved
D8110 to
8113
IP Address of the Connected Slave
Special data registers used by remote I/O.
For details, refer to Chapter 12 “4.2 Remote I/O
Master” on page 12-47.
IP Address of the
Connected Slave 1
Each second YES YES
D8114 to
8117
IP Address of the
Connected Slave 2
Each second YES YES
D8118 to
8121
IP Address of the
Connected Slave 3
Each second YES YES
D8078 to
8129
Reserved
D8130
Port Number of the Connected Slave
Special data registers used by remote I/O.
For details, refer to Chapter 12 “4.2 Remote I/O
Master” on page 12-47.
Port Number of the
Connected Slave 1
Each second YES YES
D8131
Port Number of the
Connected Slave 2
Each second YES YES
D8132
Port Number of the
Connected Slave 3
Each second YES YES
D8133
Reserved
D8134 High-Speed Counter(Group 4/I4)
These special data registers are
used with the high-speed counter
function and the frequency
measurement function.
For details, refer to Chapter 3 “4.7
High-Speed Counter” on page 3-55.
Upper Word
Current Value / Frequency
Measurement Value (I4)
Every scan YES YES
D8135 Lower Word
D8136 Upper Word
Preset Value YES YES
D8137 Lower Word
D8138 Upper Word
Reset Value YES YES
D8139 Lower Word
Device
Address
Description Updated
Ladder
FBD
bit
15
bit
0
bit
7
bit
8
Analog input AI1 (Out of range error: minimum)
Analog input AI0 (Out of range error: minimum)
Analog input AI1 (Out of range error: maximum)
Analog input AI0 (Out of range error: maximum)
3
1
2
4
5
6
To Next Page
