3 Project Settings Dialog Box
3-22 SmartAXIS Touch User's Manual
Execution Time of Control Function (msec)
Specifies the execution time for control function (5 to 1,000).
For details, refer to Chapter 12 “Execution Period” on page 12-2.
Use System Area
The System Area is an area of predetermined devices to control the screen, communicate error and time information
between the Touch and the external device. Select this check box to use the System Area. For details, refer to
“System Area” on page 3-23.
Blinking Cycle
Selects the blinking cycle (displaying a drawing object by switching it on and off at a fixed interval) as 1.0 sec or 0.5
sec.
Watch Dog
*1
Select this check box to monitor whether or not the Touch and the external device are communicating by writing a set
value (00FF (hex)) at a fixed interval.
Disable Switch
*1
Select this check box to enable and disable touch switches with a value of device.
Touch switches are enabled when the value of device is 1. They are disabled when the value of device is 0.
Use Device Cache
*1
Select this check box to execute processing by reading all the values of external devices configured for a screen when
switching the Base Screen or when displaying a Popup Screen. On the Touch, written values are reflected regardless
of this option.
Start Part with synchronous
*1
Select this check box to operate commands and HMI Special Internal Relays LSM1, LSM2, LSM3, and LSM5 after
reading all the values of external devices configured on the screen.
When this check box is cleared, all processing is immediately executed when the screen is displayed.
*1 Advanced mode only
Device: Specifies the word device to use as the System Area. The System Area is allocated starting from the
configured device address.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Use System Area 3, 4: Select this check box to use System Area 3 and 4.
Clear Keypad bit in System Area automatically
*1
:
Select this check box to automatically set the System Area 2
Numerical Input setting and Character Input setting bits to 0 after
they have been set to 1.
The System Area 2 bits cleared by this function are as follows.
Numerical Input setting complete (address+3, bit 0)
Numerical Input setting cancel (address+3, bit 1)
Character Input setting complete (address+3, bit 5)
Character Input setting cancel (address+3, bit 6)
Device: Specifies the word device to write the value.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Time (sec): Specifies the interval to write the value (1 to 65535).
Device: Specifies the bit device or bit of the word device that is read to enable or disable touch switches.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
