SmartAXIS Touch User's Manual 3-47
4 Special Functions
3
Project
● Function Description
Run/Stop Control These functions run or stop the ladder program or FBD program when the Touch is turned
on, when an error occurs, or when an external input turns on.
• Stop input
•Reset input
• Run/stop selection at memory backup error
• Run/stop selection at power up
Memory Backup These functions keep or clear Control devices (the contents of memory) when a ladder
program or FBD program starts operation. The values of the following devices can be
configured to be kept or cleared.
• Internal relays
•Shift registers
• Counters
•Data registers
Input & Output
Configuration
These options configure the special functions such as the external input filter settings and
the high-speed counter.
•High-speed counter
•Catch input
• Interrupt input
• Frequency measurement
•Input filter
• Analog input
• Timer interrupt
•Analog output
Cartridges Configure the function to use the cartridge of the Touch.
• Analog cartridge
LCD Settings Configure the LCD settings for the Touch.
• Ladder Monitor
Self Diagnostic These settings configure the watchdog timer that monitors the operating status of the
Touch.
Calendar & Clock The Touch is equipped with an internal clock and its calendar data (year, month, day, day
of the week) and clock data (hour, minute, second) which can be used in a ladder program
or FBD program. Daylight savings time can also be configured for the internal clock.
Connection Settings Configure the communication mode for using the remote I/O function with the Touch.
• Remote I/O Master
