SmartAXIS Touch User’s Manual 4-23
4 Popup Screen
4
Screen
■ Size
■ Screen List
This list shows screens that have already been created. It is only displayed when creating a new screen.
●
Options Tab
■ Background Color
Select the screen’s background color (color: 256 colors, monochrome: 8 shades). Click this button to open the color
palette. Select the color with the color palette.
■ Superimpose
Displays the Popup Screen’s background as completely transparent. The screen underneath the popup screen can be
seen.
■ Title Bar
Select this to display the title bar on the Popup Screen. The text set in Title on the General tab is displayed in the title
bar.
The title bar is not displayed if superimpose is set.
■ Close while changing Base Screen
Select this to close the displayed Popup Screen when changing the Base Screen.
Width, Height: Specify the width (40 dots to Base Screen width) and the height (40 dots to Base Screen height) of the
Popup Screen.
If you select Superimpose, the buttons underneath the Popup Screen set to superimpose are active.
Move Button:
Select this to display the (Move) button on the title bar.
Close Button:
Select this to display the (Close) button on the title bar.
