3 Goto Screen Button
7-38 SmartAXIS Touch User’s Manual
■ Action Mode
Select the behavior of the button from the following:
Back to previous Screen: Switches to the previous screen. Returns to up to 16 earlier screens.
Switch to Base Screen: Switches between Base Screen. For details, refer to Chapter 4 “3 Base Screen” on
page 4-14.
Open Popup Screen: Opens a Popup Screen. For details, refer to Chapter 4 “4 Popup Screen” on page 4-
22.
Close Popup Screen: Closes a Popup Screen. For details, refer to Chapter 4 “4 Popup Screen” on page 4-
22.
Open Device Monitor Screen: Opens the Device Monitor Screen. For details, refer to Chapter 24 “2.2 Device
Monitor” on page 24-19.
Close Device Monitor Screen: Closes the Device Monitor Screen. For details, refer to Chapter 24 “2.2 Device
Monitor” on page 24-19.
Open Ladder Monitor: Opens the Ladder Monitor. For details, refer to Chapter 24 “2.3 Ladder Monitor” on
page 24-23.
Close Ladder Monitor: Closes the Ladder Monitor. For details, refer to Chapter 24 “2.3 Ladder Monitor” on
page 24-23.
Open Password Screen: Opens the Password Screen. For details, refer to Chapter 21 “4.1 Entering the
Password on the Touch” on page 21-36.
Close Password Screen: Closes the Password Screen. For details, refer to CChapter 21 “4.1 Entering the
Password on the Touch” on page 21-36.
Open Adjust contrast Screen: Opens the Adjust contrast Screen. For details, refer to Chapter 28 “1.3 Adjusting
Screen Brightness” on page 28-2.
Close Adjust contrast Screen: Closes the Adjust contrast Screen. For details, refer to Chapter 28 “1.3 Adjusting
Screen Brightness” on page 28-2.
Switch to System Mode: Switches to the Top Page in the System Mode. For details, refer to Chapter 28 “2
System Mode Overview” on page 28-3.
Reset current screen: Resets the current Base Screen.
• Open Ladder Monitor and Close Ladder Monitor can only operate when ladder program is selected
as the programming language in control function.
• When the current Base Screen is reset using the Reset current screen function, the window and
internal devices restart as if the Base Screens were switched.
