4 Key Button
7-52 SmartAXIS Touch User’s Manual
■ Scroll Size
Key Buttons Pg. Up and Pg. Dwn scroll the list up and down, respectively. Key Buttons Fcs. Up and Fcs. Dwn move
the focus up and down, respectively. This settings specifies the number of pages or lines (1 to 1023 lines) to scroll or
move the focus per each press of the button.
This setting is enabled only if Pg. Up, Pg. Dwn, Fcs. Up, and Fcs. Dwn are selected using the Key Browser.
■ Transfer Setting
Key Buttons Download Project and Upload Project perform the data transfer function specified by their names.
These settings specify the source, data to be transfered, and destination.
This setting is enabled only if one of these keys is selected after clicking Data Transfer in the Key Browser.
If Download Project is selected.
If Upload Project is selected.
Source: This is set to the USB flash drive on which the project file to transfer (.ZNV) was saved.
File Path: Specify the path to the project file (.ZNV) to transfer. The maximum number is 247
characters.
Example: Where “FT_DEMO_1.ZNV” is a project file saved on the root directory of a USB
flash drive:
FT_DEMO_1.ZNV
Destination: Specify where to save the project uploaded from Touch. The location is the USB flash drive.
Folder Path: Specify the path to the folder where the uploaded project file will be saved. The
maximum number is 247 characters.
Example: To save it to the folder “Uploaded_Project” on a USB flash drive:
Uploaded_Project
