SmartAXIS Touch User’s Manual 7-65
4 Key Button
7
Buttons
● For Data Transfer Keys
These keys can be used to execute Data Transfer functions.
For details about Data Transfer functions, refer to Chapter 25 “Data Transfer Function” on page 25-1.
● For Alarm Displays
These keys can be used for the Alarm List Display and Alarm Log Display parts.
■ Alarm List Display
■ Alarm Log Display
Key Operation
Download Project Downloads a project file (ZNV format) saved on an external memory to the Touch.
Upload Project
Uploads the project used for operation on the Touch and saves the project file (ZNV format) to
an external memory.
Key Operation
Pg. Up Scrolls up the number of lines (1 to 1023) specified in Scroll Size.
Pg. Dwn Scrolls down the number of lines (1 to 1023) specified in Scroll Size.
Fcs. Up
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing REVERSE.
Fcs. Dwn
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing REVERSE.
REVERSE Toggles the focus between show and hide.
Ref. The reference screen appears.
Press and hold the Pg. Up, Pg. Dwn, < Cur., and Cur. > keys for more than one second to move the
focus repeatedly.
Key Operation
Fcs. Up
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing REVERSE.
Fcs. Dwn
Moves the focus the number of lines (1 to 1023) specified in Scroll Size. The current point of
focus can be shown by pressing REVERSE.
REVERSE Toggles the focus between show and hide.
CHECK Shows the date and time the alarm that has focus was confirmed.
All Chk. Shows the date and time that all alarms were confirmed.
Del. Clears the alarm that has focus.
Del. All Clears all alarms.
Ref. Shows the reference screen for the alarm that has focus.
Stop Buzzer and Screen
Flashing
Stops the sound of the buzzer and screen flashing when an alarm occurs.
Press and hold the Fcs. Up and Fcs. Dwn keys for more than one second to move the focus repeatedly.
