SmartAXIS Touch User's Manual 2-23
1 WindO/I-NV3 Specifications
2
WindO/I-NV3 Basic Operations
3 Select a graphic element from Symbols, and then click Copy.
The Picture Name Setting dialog box is displayed.
4 Enter the name of the graphic in Picture Name.
The maximum number is 256 characters.
5 Click OK.
The graphic element is saved in Picture Manager.
You cannot use the following characters in the picture name.
\ / : , ; * ? " < > |
Detailed settings can be made using Options from the Picture Name Setting dialog box. Click Options to
toggle between showing and hiding the items. For details, refer to “Picture Name Setting dialog box” on
page 2-33.
If a picture contains transparency or a picture is imported with the option of enabling the transparency, the
transparency range is displayed in magenta (R: 255, G: 4, B: 255).
To Next Page
