5 Multi-Command
11-40 SmartAXIS Touch User’s Manual
Properties of Key for Multi-Functions dialog box
Sets the Key command for the Multi-Command.
■ Command Name
Enter a name for the command. The maximum number is 20 characters.
■ Key Type
Select the function for the Key command.
The settings explained below appear depending on the type of key selected.
■ Popup Screen No.
The Alt key switches the current Popup Screen used as a Keypad when this button is pressed.
Specify the Popup Screen number to open a Keypad for.
This setting is enabled only if Alt was selected using the Key Browser.
■ Scroll Size
Key Buttons Pg. Up and Pg. Dwn scroll the list up and down, respectively. Key Buttons Fcs. Up and Fcs. Dwn move
the focus up and down, respectively. This settings specifies the number of pages or lines (1 to 1023 lines) to scroll or
move the focus per each press of the button.
This setting is enabled only if Pg. Up, Pg. Dwn, Fcs. Up, and Fcs. Dwn are selected using the Key Browser.
Displays settings
applicable to the
selected key.
(Key)
Language: Switches the display of the key that is displayed when Keypad is selected in Key Browser. These
languages are available:
Japanese, European, Central European, Baltic, Cyrillic.
Browse: Opens the Key Browser when clicked. Select a key.
For details, refer to Chapter 7 “4.5 Key Browser” on page 7-66.
(Key): Displays the name of the key selected using the Key Browser.
The function of Key command will affect on the next scan when the trigger condition is satisfied.
