6 Timer
11
Commands
● Trigger Condition Tab
When the condition has been or is satisfied, the command is executed; when not satisfied, the command is not
executed.
Example: When Trigger Type is Rising-edge and Device is LM0
The command is executed when LM0 changes from 0 to 1.
■ Trigger Type
Selects the condition to execute the command from the following.
■ Data Type
Selects the data type to be handled by the condition formula.
Can only be set if While satisfying the condition is selected as Trigger Type.
For details, refer to Chapter 2 “1.2 Available Data” on page 2-2.
LM0
:
Touch
0
LM0
:
1
Not
executed
Executed
Condition
Not
satisfied
Condition
Satisfied
While ON: Command is executed when device is 1.
While OFF: Command is executed when device is 0.
While satisfying the condition:
The command continues being executed while the condition is satisfied.
1
0
Value of Device
Action
Execution Execution Execution
1
0
Action
Value of Device
Execution Execution
Action
Condition
Satisfied
Not satisfied
Execution ExecutionExecution ExecutionExecution
