2 Ladder Program
12
Control Function
● Available Data
The available data types for each command word are as follows.
In WindLDR data types are displayed as follows: BIN16(+) as W (word), BIN16(+/-) as I (integer),
BIN32(+) as D (double word), BIN32(+/-) as L (long), and float32 as F (float).
Group
Data Type
W I D L F
Word Integer Double word Long Float
NOP NOP NO NO NO NO NO
Move
MOV YES YES YES YES YES
MOVN YES YES YES YES NO
IMOV YES NO YES NO YES
IMOVN YES NO YES NO NO
IBMV(N) YES NO NO NO NO
BMOV YES NO NO NO NO
NSET YES YES YES YES YES
NRS YES YES YES YES YES
XCHG YES NO YES NO NO
TCCST YES NO YES NO NO
Data
Comparison
CMP= YES YES YES YES YES
CMP<> YES YES YES YES YES
CMP< YES YES YES YES YES
CMP> YES YES YES YES YES
CMP<= YES YES YES YES YES
CMP>= YES YES YES YES YES
ICMP>= YES YES YES YES YES
LC= YES YES YES YES YES
LC<> YES YES YES YES YES
LC< YES YES YES YES YES
LC> YES YES YES YES YES
LC<= YES YES YES YES YES
LC>= YES YES YES YES YES
Binary
Arithmetic
ADD YES YES YES YES YES
SUB YES YES YES YES YES
MUL YES YES YES YES YES
DIV YES YES YES YES YES
INC YES YES YES YES NO
DEC YES YES YES YES NO
ROOT YES NO YES NO YES
SUM(ADD) YES YES YES YES YES
SUM(XOR) YES NO NO NO NO
Boolean
Computation
ANDW YES NO YES NO NO
ORW YES NO YES NO NO
XORW YES NO YES NO NO
