3 Configuration & Functions
2-44 SmartAXIS Touch User's Manual
■ Editing
■ Project
Command Description
Arrange
Bring to Front Moves the selected object to the front.
Send to Back Moves the selected object to the back.
Group Groups multiple objects.
Ungroup Cancels the group.
Align
Align Left Aligns selected objects to the left.
Align Center Aligns selected objects to the center.
Align Right Aligns selected objects to the right.
Align Top Aligns selected objects to the top.
Align Middle Aligns selected objects to the middle.
Align Bottom Aligns selected objects to the bottom.
Make Horizontal
Spacing Equal
Aligns selected objects to be equally spaced horizontally.
Make Vertical Spacing
Equal
Aligns selected objects to be equally spaced vertically.
Rotate
Rotate Right 90° Rotates selected drawing objects 90° to the right.
Rotate Left 90° Rotates selected drawing objects 90° to the left.
Flip Vertical Flips selected drawing objects vertically.
Flip Horizontal Flips selected drawing objects horizontally.
Replace
Automatically replaces a specified device address with a separate device
address.
Select Selects objects in the editing window.
AutoResize
Automatically changes the text size to the object’s size and display
region.
Increment Address
Enables or disables the increment address function.
A specific value is added to the value of the object’s device address when
pasting and duplicating parts.
Command Description
Download
Project Data Downloads project data to the Touch.
Files to External Memory
Stops the Touch and then downloads Recipe files (CSV file) to the
external memory inserted in the Touch. The Touch resumes running
when files have finished downloading.
Files to External Memory
while running
Downloads Recipe files (CSV file) to the external memory inserted in the
Touch without stopping it.
Upload
Project Data Uploads project data from the Touch.
Stored Data in External
Memory
Uploads data from the External Memory Folder for the currently running
project.
Compare
Compare Projects
Compares the screen data and scripts in an existing project with the
project data currently being edited and displays the results of that
comparison.
Re-verify Updates the comparison results to the most latest state.
Target Info.
Displays version information for the Touch runtime system and project
information.
Comm.Setup
Configures the communication target and communication conditions
between the target and the Touch or between the computer and the
Touch.
