1 Overview
14-4 SmartAXIS Touch User’s Manual
● Sampling Values of Devices when Value of Device Changes
When sampling values of devices (D100 to D102), when a bit device configured as the sampling condition switches
from 0 to 1 and the data storage amount in the data storage area is set to 3, the Touch samples Data Log data as
follows.
1 When data sampling starts and the bit device configured as the sampling condition switches from 0 to 1, the Touch
stores the values for devices D100 to D102.
2 When the sampling condition device switches from 0 to 1 the second time, the Touch stores the values for devices
D100 to D102.
3 When the sampling condition device switches from 0 to 1 the third time, the Touch stores the values for devices D100
to D102.
4 When the sampling condition device switches from 0 to 1 the fourth time, the Touch stores the values for devices
D100 to D102.
Since the data storage amount in the data storage area is set to 3, the oldest data is deleted in order to make room
for the newest data.
Tou ch
External device
D100 D101 D102
20 80 2
0
1
0
1
0
1
0
1
ataDseciveD fo seulaV stored on the Touch
Time
Value
Sampling Time
Value
3 ataD2 ataD1 ataD201D101D001D
01/01/2011 12:01:00 10 70 3 01/01/2011 12:05:00 20 80 2
01/01/2011 12:02:00 20 80 2 01/01/2011 12:13:00 10 70 3
01/01/2011 12:03:00 30 90 1 01/01/2011 12:15:00 30 90 1
01/01/2011 12:04:00 10 70 3
01/01/2011 12:05:00 20 80 2
01/01/2011 12:06:00 30 90 1
01/01/2011 12:07:00 10 70 3
01/01/2011 12:08:00 20 80 2
01/01/2011 12:09:00 30 90 1
01/01/2011 12:10:00 10 70 3
01/01/2011 12:11:00 20 80 2
01/01/2011 12:12:00 30 90 1
01/01/2011 12:13:00 10 70 3
01/01/2011 12:14:00 20 80 2
01/01/2011 12:15:00 30 90 1
01/01/2011 12:16:00 10 70 3
1
2
3
0
1
hcuoT eht no derots ataDseciveD fo seulaV
Time
Value
Sampling Time
Value
3 ataD2 ataD1 ataD201D101D001D
·
·
·
·
·
·
·
·
·
·
·
·
01/01/2011 12:17:00 40 60 2 01/01/2011 12:13:00 10 70 3
01/01/2011 12:18:00 30 60 1 01/01/2011 12:15:00 30 90 1
01/01/2011 12:19:00 10 90 3 01/01/2011 12:20:00 20 80 2
01/01/2011 12:20:00 20 80 2
4
