SmartAXIS Touch User’s Manual 17-5
2 Preventive Maintenance Function Configuration Procedure
17
Preventive Maintenance Function
6 Select the Measure Operation Time check box on the Operation Time tab.
If you are not counting the operation time, leave the Measure Operation Time check box cleared and proceed to
step
9.
7 Specify the destination device for the counted operation time.
You can only specify an HMI Keep Register (LKR).
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-62.
8 Select the data type for the value of the Measure Operation Time device from Data Type.
This concludes configuring operation time counting.
9 Click the Operation Count tab.
10
Select the Measure Operation Count check box.
If you are not counting the operation count, leave the Measure Operation Count check box cleared and proceed to
step
13
.
11
Specify the destination device for the counted operation count.
You can only specify an HMI Keep Register (LKR).
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-62.
12
Select the data type for the value of the Measure Operation Count device from Data Type.
This concludes configuring operation count counting.
13
Click OK to close the Individual Settings dialog box.
14
Repeat steps 2 through
13
to register settings to count the operation time and operation count in all the used
numbers.
This concludes configuring operation time and operation count counting.
Next, configure the functions to execute using counted data.
F “4.1 Displaying the Counted Operation Count on a Numerical Display” on page 17-11
F “4.2 Notifying with a Beep when the Counted Operation Time Reaches the Threshold” on page 17-14
