3 Preventive Maintenance Settings Dialog Box
17-10 SmartAXIS Touch User’s Manual
■ Data Type
Select the data type for the operation count device as BIN16 (+) or BIN32 (+). For details, refer to Chapter 2 “1.2
Available Data” on page 2-2.
■ Report when Operation Count has reached or exceeded Threshold level
Select this check box to report when the counted operation count reaches or exceeds the threshold.
■ (Data Type)
Selects the type of data for the threshold.
■ Level 1
Configures the level 1 threshold and report device.
■ Level 2
Select this check box to configure the level 2 threshold and report device.
■ Level 3
Select this check box to configure the level 3 threshold and report device.
Value: Uses a constant as the threshold.
Device: Uses a value of device as the threshold.
Threshold Specifies the count as a constant or a device that is the criterion for reporting at level 1. For a
constant, the range that can be set varies based on the data type. For a device, click to
display the Device Address Settings dialog box. For the device address configuration procedure,
refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Report Device: Specifies the bit device or bit of the word device for reporting when the operation count reaches
or exceeds the level 1 threshold.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Threshold Specifies the count as a constant or a device that is the criterion for reporting at level 2. For a
constant, the range that can be set varies based on the data type. For a device, click to
display the Device Address Settings dialog box. For the device address configuration procedure,
refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Report Device: Specifies the bit device or bit of the word device for reporting when the operation count reaches
or exceeds the level 2 threshold.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Threshold Specifies the count as a constant or a device that is the criterion for reporting at level 3. For a
constant, the range that can be set varies based on the data type. For a device, click to
display the Device Address Settings dialog box. For the device address configuration procedure,
refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Report Device: Specifies the bit device or bit of the word device for reporting when the operation count reaches
or exceeds the level 3 threshold.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
To Next Page
