2 Text Groups and Text Configuration Procedure
19-4 SmartAXIS Touch User’s Manual
4 In Default Group, select the text group to use when the Touch power is turned on and when switched to run mode.
5 Select the Use Dynamic Text check box.
6 With Trigger Device, specify the word device to use as the condition to switch the text group.
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-62.
These options can only be configured when Number of Text Groups is specified as two or more.
7 Click OK to close the Text Group Settings dialog box.
This concludes creating text groups.
When the value of device is 0, the text group switches to the default group.
If the value of device is invalid, the text group is not switched.
