EXi: CX-3 Tonewheel Organ
198
AMS Mode [Toggle, Momentary]
This determines the behavior of the Vibrato/Chorus AMS for
the Upper drawbars. For details, see “AMS Mode” on
page 189.
Lower Drawbars V/C [Off, On]
This routes the lower drawbars through the Vibrato/Chorus.
AMS [List of AMS Sources]
This selects an AMS source to turn Vibrato/Chorus on or off
for the Upper Drawbars. For a list of AMS sources, see
“Alternate Modulation Source (AMS) List” on page 901.
AMS Mode [Toggle, Momentary]
This determines the behavior of the Vibrato/Chorus AMS for
the Upper drawbars. For details, see “AMS Mode” on
page 189.
Input Trim [000…100]
This controls the input level to the Vibrato/Chorus.
It applies only to the set(s) of drawbars routed through the
Vibrato/Chorus, via the V/C On/Off buttons above. You can
use this to compensate for volume level differences between
the output of the Vibrato/Chorus and the dry signal, so that
the volume stays constant when you switch the V/C on or
off.
Note that the output volume of the V/C will vary, depending
on the selected Preset or the settings of the Custom
parameters.
Mode [Preset/Custom]
When Mode is set to Preset, the Vibrato/Chorus will use the
settings under Preset, below. These are the classic V1-3 and
C1-3 settings.
When Mode is set to Custom, the Vibrato/Chorus uses the
settings under Custom, below. These allow you to create
your own versions of the effect.
7–1d: Preset
These parameters are available only if the Mode, above, is
set to Preset.
Type [V1, C1, V2, C2, V3, C3]
This selects one of the six classic Vibrato/Chorus presets.
“V” stands for Vibrato, and “C” stands for Chorus.
AMS [List of AMS Sources]
This selects an AMS source to modulate the Type. For a list
of AMS sources, see “Alternate Modulation Source (AMS)
List” on page 901.
Intensity [–05…+05]
This controls the depth and direction of the AMS modulation
for the Type.
7–1e: Custom
These parameters are available only if the Mode, above, is
set to Custom.
Mix [0…100]
This adjusts the balance between the Vibrato and Chorus
effects. 0 is all Vibrato; 100 is all Chorus.
AMS [List of AMS Sources]
This selects an AMS source to modulate the Mix. For a list
of AMS sources, see “Alternate Modulation Source (AMS)
List” on page 901.
Intensity [-100…+100]
This controls the depth and direction of the AMS modulation
for Mix.
Depth [0…100]
This sets the depth of Vibrato/Chorus modulation. Higher
values mean greater pitch and volume modulation.
AMS [List of AMS Sources]
This selects an AMS source to modulate the Depth. For a list
of AMS sources, see “Alternate Modulation Source (AMS)
List” on page 901.
Intensity [-100…+100]
This controls the depth and direction of the AMS modulation
for Depth.
Speed [0.2Hz…20Hz]
This controls the speed of the Vibrato/Chorus LFO.
0 is 0.02Hz; 230 is 20 Hz; and 180 is 7Hz. Try around 179
for the magic C3 frequency.
AMS [List of AMS Sources]
This selects an AMS source to modulate the Speed. For a list
of AMS sources, see “Alternate Modulation Source (AMS)
List” on page 901.
Intensity [-20Hz…0Hz…+20Hz]
This controls the depth and direction of the AMS modulation
for Speed.
7–1f: Main Output
Output Level [000…127]
This controls the overall output level, after the Amp section
and the Expression controls. In other words, this affects only
the volume of the sound, and not the tonal character.
AMS [List of AMS Sources]
This selects an AMS source to modulate the Output Level.
For a list of AMS sources, see “Alternate Modulation Source
(AMS) List” on page 901.
Intensity [–127…+127]
This controls the depth and direction of the AMS modulation
for Output Level.
Pan [Random, L001…C064…R127]
This controls the stereo pan of the organ. A setting of L001
places the sound at the far left, C064 in the center, and R127
to the far right.
