Mono-Mono Serial 140: Reverb - Gate
875
High Damp [%] [0…100]
Sets the amount of high-frequency attenuation.
Reverb Time [sec] [0.1…10.0]
Sets the reverberation time.
Wet/Dry [Dry, 1:99…99:1, Wet]
Sets the reverb effect balance.
GATE
For details on the Gate graphics, see “009: Stereo Gate” on
page 772.
CONTROL
Envelope Select [Dmod, Input]
This chooses whether the gate is triggered by the signal
level, or controlled directly by the selected Dmod Source.
When Envelope Select is set to Input, the gate is controlled
by a blend of the dry audio input and the reverb output, as set
by the Input Reverb Mix.
Source [Off…Tempo]
Selects the modulation source that controls the gate when
Envelope Select is set to Dmod.
Input Reverb Mix [Dry, 1:99…99:1, Wet]
This mixes the dry input and reverb output signals, for
controlling the gate.
Normally, set Input Reverb Mix to Dry, so that the gate is
controlled only by the dry input. If you wish to extend the
gate time, increase the Input Reverb Mix value to include
some of the wet mix as well, and adjust the Threshold.
GATE
Threshold [0…100]
Sets the gate threshold level. When the signal level exceeds
the threshold, the gate opens and the reverb sound is heard.
Note that this applies only when Envelope Select is set to
Input. When the gate is controlled via Dmod, it opens when
the Dmod value is 64 or higher, and closes when the value is
63 or lower.
Attack [1…100]
Sets the attack time. See “Attack” on page 772.
Release [1…100]
Sets the release time. See “Release” on page 772.
Polarity [+, –]
This lets you invert the gate on/off state
. See “Polarity” on
page 772.
OUTPUT
This is the standard effects output section, with modulatable
control over wet/dry balance. For more information, see
“OUTPUT” on page 762.
