Concepts and Features
R&S
®
ZNB/ZNBT
201User Manual 1173.9163.02 ─ 55
5.7.1 Additional Test Ports (R&S ZNBT only)
Various Options
The R&S ZNBT8 is available with a minimum of 4 test ports (order number
1318.7006.24) that are either equipped with standard or with Extended Dynamic
Range reflectometers (option ZNBT8-B504).
The base unit can be extended by additional blocks of 4 ports, up to a maximum of 24
ports. Again, these additional port blocks can either be equipped with standard reflec-
tometers or with Extended Dynamic Range reflectometers. Mixed equipping is suppor-
ted.
Table 5-17: Additional Test Ports for R&S
ZNBT8
Standard Reflectometers Extended Dynamic Range
5 to 8 R&S ZNBT8-B108 R&S ZNBT8-B508
9 to 12 R&S ZNBT8-B112 R&S ZNBT8-B512
13 to 16 R&S ZNBT8-B116 R&S ZNBT8-B516
17 to 20 R&S ZNBT8-B120 R&S ZNBT8-B520
21 to 24 R&S ZNBT8-B124 R&S ZNBT8-B524
Analyzers R&S ZNBT20|26|40, on the other hand, are available with a minimum of 8
test ports (order number 1332.9002.24|34|44). They can be extended with additional
blocks of 4 ports, up to a maximum of 24 ports.
Extended Dynamic Range reflectometers are not available for these models.
Table 5-18: Additional Test Ports for R&S
ZNBT20|26|40
9 to 12 R&S ZNBT20|26|40-B112
13 to 16 R&S ZNBT20|26|40-B116
17 to 20 R&S ZNBT20|26|40-B120
21 to 24 R&S ZNBT20|26|40-B124
The instrument needs to be returned to Rohde & Schwarz service for ex post installa-
tion of additional ports.
5.7.2 Time Domain Analysis
Option R&S ZNB-K2 / R&S ZNBT-K2
The network analyzer measures and displays complex S-parameters and other quanti-
ties as a function of the frequency. The measurement results can be filtered and math-
ematically transformed to obtain the time domain representation, which often gives a
clearer insight into the characteristics of the DUT.
Optional Extensions and Accessories
