GUI Reference
R&S
®
ZNB/ZNBT
475User Manual 1173.9163.02 ─ 55
Back
Go back to Step 2: Connectors and Cal Kits.
Start
Start Step 3: Calibration.
Step 3: Calibration
Allows you to acquire error correction data for every required port (pair) and calibration
standard, plus power correction data from the power meter.
Same functionality as for the single calibration version of the wizard (see "Step 3: Cali-
bration" on page 434).
●
The order of the system error correction and power calibration sweeps is arbitrary,
but make sure that you always connect the proper equipment.
The possibility to "share" measurements between the calibrations and the "Reduced
Through" logic help to keep the number of measurements as small as possible (see
Chapter 5.5.1.11, "Full n-Port Calibration with Reduced Number of Through Connec-
tions", on page 158).
6.11.2 Cal Devices Tab
Provides access to all functions for calibration kit management and cal unit characteri-
zation.
Background information
Refer to the following sections:
●
Chapter 5.5.2, "Calibration Standards and Calibration Kits", on page 159
●
Chapter 5.5.5.3, "Characterization of Calibration Units", on page 170
The buttons in the "Cal Devices" tab open the following dialogs:
●
"Cal Connector Types...": See Chapter 6.11.2.1, "Cal Connector Types Dialog",
on page 476
●
"Cal Kits...": See Chapter 6.11.2.2, "Calibration Kits Dialog", on page 478
●
"Characterize Cal Unit...": See Chapter 6.11.2.3, "Characterize Cal Unit Dialog",
on page 483
Cal Softtool
