CALCulate<Chn>:DATA:STIMulus?
Reads the stimulus values of the active data or memory trace.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Example: See CALCulate<Chn>:DATA
Usage: Query only
8.3.1.3
CALCulate:DLINe...
The CALCulate:DLINe... commands control the horizontal line used to mark and
retrieve response values (display line).
CALCulate<Chn>:DLINe.................................................................................................790
CALCulate<Chn>:DLINe:STATe.......................................................................................790
CALCulate<Chn>:DLINe <Position>
Defines the position (response value) of the horizontal line.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Position> See list of parameters below.
Default unit: NN
Example:
*RST; :CALC:DLIN 10
Define the position of the horizontal line in the default dB Mag
diagram at +10 dB.
CALC:DLIN:STAT ON
Display the defined horizontal line.
Manual operation: See "Response Value" on page 359
CALCulate<Chn>:DLINe:STATe <Boolean>
Switches the horizontal line on or off.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> ON | OFF - horizontal line on or off
*RST: OFF
Example: See CALCulate<Chn>:DLINe
Manual operation: See "Show Horiz. Line" on page 359
