HANN - normal profile (Hann)
HAMMing - low first sidelobe (Hamming)
BOHMan - steep falloff (Bohman)
DCHebyshev - arbitrary sidelobes (Dolph-Chebychev)
*RST: HANN
Example: See CALCulate<Chn>:TRANsform:TIME:DCHebyshev
Manual operation: See "Impulse Response" on page 318
CALCulate<Chn>:TRANsform:TIME:XAXis <Unit>
Switches over between the x-axis scaling in time units or distance units.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Unit> TIME | DISTance
TIME - x-axis scaled in time units.
DISTance - x-axis scaled in distance units (Distance = Time * c
0
* Velocity Factor).
Example:
*RST; :CALC:TRAN:TIME:STAT ON
Reset the instrument, activating a frequency sweep, and enable
the time domain transformation for the default trace.
CALC:TRAN:TIME:XAX DIST
Convert the x-axis scaling to distance units.
Manual operation: See "Time / Distance" on page 387
8.3.1.21 CALCulate:TRANsform:DTFault...
The CALCulate:TRANsform:DTFault... commands set up and control a distance
to fault measurement (with option R&S ZNB/ZNBT-K3).
CALCulate<Chn>:TRANsform:DTFault:DEFine.................................................................935
CALCulate<Chn>:TRANsform:DTFault:DELete.................................................................935
CALCulate<Chn>:TRANsform:DTFault:SELect................................................................. 936
CALCulate<Chn>:TRANsform:DTFault:CENTer................................................................ 936
CALCulate<Chn>:TRANsform:DTFault:SPAN................................................................... 936
CALCulate<Chn>:TRANsform:DTFault:PEAK:COUNt?......................................................937
CALCulate<Chn>:TRANsform:DTFault:PEAK:DATA<FaultNo>...........................................937
CALCulate<Chn>:TRANsform:DTFault:PEAK:STATe......................................................... 937
CALCulate<Chn>:TRANsform:DTFault:PEAK:THReshold.................................................. 938
CALCulate<Chn>:TRANsform:DTFault:POINts................................................................. 938
CALCulate<Chn>:TRANsform:DTFault:STARt.................................................................. 939
CALCulate<Chn>:TRANsform:DTFault:STOP...................................................................939
CALCulate<Chn>:TRANsform:DTFault:STATe.................................................................. 939
