R&S ZNB - 8.3.1.7 CALCulate:FMODel...; CALCulate:FMODel:ISD...

Command Reference
R&S
®
ZNB/ZNBT
823User Manual 1173.9163.02 ─ 55
CALCulate<Chn>:FILTer[:GATE]:TIME:WINDow <TimeGate>
Selects the time gate to be applied to the time domain transform.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<TimeGate> RECT | HAMMing | HANNing | BOHMan | DCHebyshev
RECT - steepest edges (rectangle)
HANN - normal gate (Hann)
HAMMing - steep edges (Hamming)
BOHMan - minimum flatness (Bohman)
DCHebyshev - arbitrary gate shape (Dolph-Chebychev)
*RST: HANN
Example: See CALCulate<Chn>:FILTer[:GATE]:TIME:DCHebyshev
Manual operation: See "Shape" on page 323
8.3.1.7
CALCulate:FMODel...
The CALCulate:FMODel... commands are related to "fixture modeling" tools (see
Chapter 5.6.2.9, "Fixture Modeling and Deembedding", on page 196).
In the current implementation the firmware assumes that balanced fixture modeling
and dembedding is required, whenever a balanced port is configured.
A mixture of single-ended and balanced fixture modeling is not supported.
CALCulate:FMODel:ISD...
Commands for AtaiTec's In Situ De-Embedding (ISD) tool, see http://ataitec.com/prod-
ucts/isd/
CALCulate:FMODel:ISD<Ph_pt>:ATTenuation:BEHavior....................................................824
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure........................................................ 824
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:FILename......................................... 824
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:OPEN.............................................. 825
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:OPEN:FILename...............................825
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:SHORt............................................. 825
CALCulate:FMODel:ISD<Ph_pt>:COUPon:MEASure:SHORt:FILename..............................826
CALCulate:FMODel:ISD<Ph_pt>:COUPon:TYPE..............................................................826
CALCulate:FMODel:ISD<Ph_pt>:COUPon[:STATe]........................................................... 826
CALCulate:FMODel:ISD<Ph_pt>:DCEXtrapolat................................................................ 826
CALCulate:FMODel:ISD<Ph_pt>:DUT:MEASure............................................................... 827
CALCulate:FMODel:ISD<Ph_pt>:DUT:TYPE.....................................................................827
CALCulate:FMODel:ISD<Ph_pt>:DUT[:STATe]..................................................................827
CALCulate:FMODel:ISD<Ph_pt>:FTIMe:DUT................................................................... 828
CALCulate:FMODel:ISD<Ph_pt>:FTIMe:OVERride........................................................... 828
CALCulate:FMODel:ISD<Ph_pt>:OPERation....................................................................828
CALCulate:FMODel:ISD<Ph_pt>:PASSivity...................................................................... 829
SCPI Command Reference
