R&S ZNB - Summary

GUI Reference
R&S
®
ZNB/ZNBT
664User Manual 1173.9163.02 ─ 55
Depending on the "Measurement Selection" on page 663 either one, two, or three
channels must be set up:
●
one channel for S-parameter measurements
●
one channel for intermodulation measurements
Summary
The "Summary" page of the "DUT Sentric Wizard"
●
summarizes which channels will be created and which parameters they will mea-
sure
●
allows you where to define these channels (new setup, append to current setup,
replace current setup)
●
allows you to decide whether to proceed with a (suitable) calibration
Applic Softtool
