Concepts and Features
R&S
®
ZNB/ZNBT
230User Manual 1173.9163.02 ─ 55
5.7.9 In-situ De-Embedding
Option R&S ZNB-K220/R&S ZNBT-K220
This option offers a pre-installed or service-retrofitted version of AtaiTec's In Situ De-
Embedding (ISD) tool for fixture de-embedding.
The tool is integrated into the de-embedding functionality of the analyzer firmware.
●
For general information about fixture de-embedding, see Chapter 5.6.2.9, "Fixture
Modeling and Deembedding", on page 196.
●
For detailed information about the ISD tool, see the product pages at http://atai-
tec.com/products/isd/
5.7.10 Smart Fixture De-Embedding
Option R&S ZNB-K230/R&S ZNBT-K230
This option offers a pre-installed or service-retrofitted version of PacketMicro's Smart
Fixture De-embedding (SFD) for fixture de-embedding.
The tool is integrated into the de-embedding functionality of the analyzer firmware.
●
For general information about fixture de-embedding, see Chapter 5.6.2.9, "Fixture
Modeling and Deembedding", on page 196.
●
For detailed information about the SFD tool, see the product pages at https://
www.packetmicro.com/Products/sfd-tool.html.
5.7.11 Delta-L 4.0 PCB Characterization
Option R&S ZNB-K231/R&S ZNBT-K231
Delta-L is a de-embedding methodology developed by Intel Corporation and is used for
de-embedding strip lines that include vias. Delta-L calculates the loss of PCB intercon-
nects and can be performed on single-ended or balanced interconnects.
The objective of Delta-L is to determine an insertion loss measurement defined on two
or more coupon lines of differing lengths. This ratio of insertion loss in dB/inch can be
applied to any trace length with similar vias.
For background information, see
●
https://www.intel.com/content/dam/www/public/us/en/documents/guides/delta-l-
plus-methodology-for-electrical-characterization-guide.pdf
●
https://ieeexplore.ieee.org/document/7048423
Optional Extensions and Accessories
