R&S ZNB User Manual

Command Reference
R&S
®
ZNB/ZNBT
1323User Manual 1173.9163.02 ─ 55
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:RELays:SWITch:COUNt?
For mechanical matrices, this command allows to query the list of switch counts for all
relays (if supported by the matrix).
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1319)
Usage: Query only
Manual operation: See "Configured External Switch Matrices" on page 713
SYSTem:COMMunicate:RDEVice:SMATrix<Matr>:SERial?
Returns the serial number of the related switch matrix.
Suffix:
<Matr>
.
Index of the switch matrix (see SYSTem:COMMunicate:
RDEVice:SMATrix<Matr>:DEFine on page 1319)
If the switch matrix is not part of the RF configuration, the query
returns an "Invalid suffix" error.
Usage: Query only
Manual operation: See "Configured Devices" on page 731
8.3.17.2 SYSTem:DATA:MEMory...
These commands allow you to configure memory-mapped trace data transfer. See
Chapter 5.4.3, "Memory-Mapped Trace Data Transfer", on page 145.
SYSTem:DATA:MEMory:ADD <TraceName>, <DataFormat>, <NumberOfPoints>
Adds trace <TraceName> to a previously initialized shared memory buffer.
Traces can only be added after the SYSTem:DATA:MEMory:INITalize and before
the corresponding SYSTem:DATA:MEMory:COMMit.
For background information, see Chapter 5.4.3, "Memory-Mapped Trace Data Trans-
fer", on page 145.
Setting parameters:
<TraceName> Trace name. Identifies the trace within the active recall set.
<DataFormat> SDATa | FDATa
The data format of the stored trace values.
SDATa
Unformatted (complex) trace data.
FDATa
Formatted (real-valued) trace data.
<NumberOfPoints> Number of trace values to be stored.
