GUI Reference
R&S
®
ZNB/ZNBT
339User Manual 1173.9163.02 ─ 55
Access: The dialog may be called from several dialogs, for example on pressing
"Open" in the Import Complex Data Dialog.
Select All / Deselect All
During trace data import, selects/deselects all traces contained in the opened trace file.
Auto Distribute
Available for trace data import only.
If checked, a selected trace S
ij
is imported as a memory trace for all data traces in the
current recall set that are measuring S
ij
.
Remote command:
MMEMory:LOAD:TRACe:AUTO
6.5.11.4 Select Ports Dialog
The "Select Ports" dialog defines the port assignment for the created Touchstone
(*.s<n>p) file.
Access: TRACE – [TRACE CONFIG] > "Trace Data" > "snp Free Config..."
Touchstone files and file export
Note the conditions described in "Conditions for Touchstone file export" on page 142.
Trace Config Softtool
To Next Page
