[SENSe<Ch>:]ROSCillator[:SOURce] <Source>
Selects the source of the reference oscillator signal.
Parameters:
<Source> INTernal | EXTernal
INTernal – internal 10 MHz reference oscillator
EXTernal – external reference clock
The frequency of the external reference clock can be defined
using [SENSe:]ROSCillator:EXTernal:FREQuency
*RST: INTernal
Example: See [SENSe:]ROSCillator:EXTernal:FREQuency
on page 1218.
Manual operation: See "Internal/External" on page 714
[SENSe:]ROSCillator:EXTernal:FREQuency <ExtClockFreq>
Specifies or queries the frequency of the external reference oscillator.
Parameters:
<ExtClockFreq> Frequency of the external reference clock signal.
Range: See the data sheet of your analyzer.
*RST: 10 MHz
Default unit: Hz
Example:
ROSC EXT
Select the external reference clock as clock source.
ROSC:EXT:FREQ 10MHz
Specify the frequency of the external reference clock.
ROSC:EXT:FREQ?
Query the frequency of the external reference oscillator. The
response is 10000000 Hz.
Manual operation: See "Ext Frequency" on page 715
8.3.14.18 [SENSe:]SEGMent<Seg>...
The [SENSe:]SEGMent<Seg>... commands define all channel settings for a seg-
mented frequency sweep. A segmented sweep is activated via [SENSe<Ch>:
]SWEep:TYPE SEGMent.
The commands in this subsystem do not accept the step parameters UP and DOWN.
Numeric values can be entered directly or using the DEFault, MINimum, MAXimum
parameters.
[SENSe<Ch>:]SEGMent:COUNt?..................................................................................1219
[SENSe<Ch>:]SEGMent<Seg>[:STATe]......................................................................... 1220
[SENSe<Ch>:]SEGMent<Seg>:ADD..............................................................................1220
