GUI Reference
R&S
®
ZNB/ZNBT
545User Manual 1173.9163.02 ─ 55
6.12.4 Intermod. Tab
Controls the intermodulation measurement including power calibration. The intermodu-
lation measurement requires options R&S ZNB/ZNBT-K4 and R&S ZNB/ZNBT-K14.
The results can be selected using the "Intermod." tab of the "Meas" softtool, see Chap-
ter 6.2.4, "Intermod. Tab", on page 271.
The Intermodulation Presetting Wizard guides through the measurement configuration.
Background information
Refer to Chapter 5.7.4.3, "Intermodulation Measurements", on page 220.
6.12.4.1 Controls on the Intermod Tab
The buttons on the "Intermod" tab open the following dialogs:
●
"Intermod Wizard...": See Chapter 6.12.4.2, "Intermodulation Presetting Wizard",
on page 547
●
"Define Intermod...": See Chapter 6.12.4.3, "Define Intermodulation Distortion
Measurement Dialog", on page 551
●
"Frequencies Powers...": See Chapter 6.12.4.4, "Frequencies and Power Dialog",
on page 554
●
"Generators...".: See Chapter 6.17.4.4, "External Generators Dialog",
on page 723
●
"Intermod Pwr Cal...": See Chapter 6.12.4.5, "Intermod. Pwr. Cal Wizard",
on page 555
Channel Config Softtool
