Command Reference
R&S
®
ZNB/ZNBT
1049User Manual 1173.9163.02 ─ 55
Note that no error is generated if a valid <MenuKey> is specified but the tab cannot be
activated for any other reason.
Setting parameters:
<MenuKey> Identifier of a softtool tab
Example:
*RST; DISP:MENU:KEY:SEL ':Meas:SParams'
Activates the "S-Params" tab of the "Meas" softtool.
Usage: Setting only
Tip: When working with the GPIB Explorer, switch to raw mode ("Options > Raw
mode" in the IECWIN32 GUI) before executing this command.
DISPlay:MENU:KEY:TOOL:CATalog?
Displays the identifiers of the available softtool tabs as a comma-separated list of
strings.
Use DISPlay:MENU:KEY:SELect to activate one of the tabs.
Usage:
Query only
DISPlay:RFSize <RelFontSize>
Defines the size of the fonts in the diagram on a relative scale.
Parameters:
<RelFontSize> Relative font size
Range: 80 % to 170 %
*RST: 100 %
Default unit: percent
Example:
*RST; :DISP:RFS 80
Use smaller fonts to gain more space for the traces in the dia-
gram.
Manual operation: See "Font Size" on page 690
8.3.6 FORMat Commands
The FORMAT... commands select a data format for transferring numeric data (includ-
ing arrays) from and to the analyzer.
FORMat[:DATA]........................................................................................................... 1049
FORMat:BORDer.........................................................................................................1050
FORMat[:DATA] <TransferFormat>[, <Length>]
Selects the format for numeric data transferred to and from the analyzer.
