6.12.4.3 Define Intermodulation Distortion Measurement Dialog
The dialog configures the intermodulation measurement (except for power and fre-
quency settings). The "OK" button is available when a valid configuration has been
defined.
Access: CHANNEL – [CHANNEL CONFIG] > "Intermod" > "Define Intermod..."
Independent sources for the lower and upper tone requires a R&S ZNB/ZNBT with two
internal sources (see Chapter 5.7.13, "Internal Second Source", on page 232). Alterna-
tively an external generator can be used, see Chapter 5.7.4.3, "Intermodulation Mea-
surements", on page 220.
