One path two port OPTPort 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK',
'TRANSTRACK'
TOSM TOSM 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK',
'LOADMATCH', 'TRANSTRACK'
TOM, TSM, TRM, TRL, TNA TOM | TSM | TRM | TRL | TNA 'DIRECTIVITY', 'SRCMATCH', 'REFLTRACK',
'LOADMATCH', 'TRANSTRACK' (for reading and
writing)
'G11' ... 'G22' and 'H11', 'H12', 'H22' (for reading
only; the 'H21' matrix elements are normalized to
1)
8.3.14.4 [SENSe:]CORRection:SMATrix:CDATa...
The [SENSe:]CORRection:SMATrix:CDATa... commands read or write system
error correction data in the presence of switching matrices (see Chapter 5.7.27, "Exter-
nal Switch Matrices", on page 245).
[SENSe<Ch>:]CORRection:SMATrix:CDATa <ErrorTerm>, <SourceTestPort>,
<LoadTestPort>, <SourceVNAPort>, <LoadVNAPort>, <CorrectionData>...
[SENSe<Ch>:]CORRection:SMATrix:CDATa:PORT<PhyPt> <ErrorTerm>,
<SourceTestPort>, <LoadTestPort>, <SourceVNAPort>, <LoadVNAPort>,
<CorrectionData>...
Writes or reads system error correction data in the presence of switching matrices.
Same command structure and logic as for [SENSe:]CORRection:CDATa... commands,
except for additional parameters SourceVNAPort and LoadVNAPort that restrict the
returned correction data to the measurement path between by the respective physical
VNA ports (if any). See Chapter 5.7.27.5, "Multiple Paths and Calibration",
on page 251 for details.
Suffix:
<Ch>
.
<PhyPt>
Parameters:
<ErrorTerm>
<SourceTestPort>
<LoadTestPort>
<SourceVNAPort> Number of the VNA port connected to the source test port (via
switch matrix)
<LoadVNAPort> Number of the VNA port connected to the load test port (via
switch matrix)
<CorrectionData> Correction data either in ASCII or block data format, depending
on the current FORMat[:DATA] setting.
