Note: The loaded file is stored in the active recall set. Persisted recall sets contain the
full de-/embedding data so that they can be transferred to other instruments.
Remote command:
MMEMory:LOAD:VNETworks<Ch>:PPAir:DEEMbedding<ListId>
MMEMory:LOAD:VNETworks<Ch>:PPAir:EMBedding<ListId>
6.13.7 Balanced Tab
Selects 4-port transformation networks for balanced port deembedding/embedding,
defines their parameters, assigns them to a balanced port and enables embedding.
Use the complementary dock widget to create Balanced Panel and to activate or deac-
tivate dembedding/embedding for selected balanced ports (see Chapter 6.13.1.5, "Bal-
anced Panel", on page 574).
Background information
Refer to the section Chapter 5.6.2.10, "Combining Several De-/Embedding Networks",
on page 198.
