Command Reference
R&S
®
ZNB/ZNBT
832User Manual 1173.9163.02 ─ 55
Parameters:
<FltLeadInScalingTime>
Manual operation: See "Scaling for Flt Tm" on page 597
CALCulate:FMODel:ISD<Ph_pt>:TRACe:COUPling <TraceCoupling>
Tells the ISD tool about coupling among lead-in traces.
Corresponds to the coupling batch mode parameter of the ISD tool.
Suffix:
<Ph_pt>
.
This suffix is ignored.
Parameters:
<TraceCoupling> NONE | WEAK | STRong
NONE: no coupling.
WEAK: coupling will be extracted even if there are 2 ports
enabled on the test coupon
STRong: if the test coupon is a 4-port file, and there are two
ports to be extracted, the ISD tool will optimize odd- and even-
mode insertion losses
Manual operation: See "Trace Coupling" on page 599
CALCulate:FMODel:SFD...
Commands for PacketMicro's Smart Fixture De-embedding (SFD), see https://
www.packetmicro.com/Products/sfd-tool.html
CALCulate:FMODel:SFD<Ph_pt>:AUTO.......................................................................... 832
CALCulate:FMODel:SFD<Ph_pt>:COUPon:MEASure....................................................... 833
CALCulate:FMODel:SFD<Ph_pt>:COUPon:MEASure:FILename........................................833
CALCulate:FMODel:SFD<Ph_pt>:COUPon:TYPE.............................................................833
CALCulate:FMODel:SFD<Ph_pt>:COUPon[:STATe].......................................................... 833
CALCulate:FMODel:SFD<Ph_pt>:DIFFcfg........................................................................834
CALCulate:FMODel:SFD<Ph_pt>:DUT:MEASure.............................................................. 834
CALCulate:FMODel:SFD<Ph_pt>:DUT[:STATe].................................................................834
CALCulate:FMODel:SFD<Ph_pt>:RUN:RUN.................................................................... 835
CALCulate:FMODel:SFD<Ph_pt>:RUN[:STATe]................................................................ 835
CALCulate:FMODel:SFD<Ph_pt>:TOTaldiffcfg..................................................................835
CALCulate:FMODel:SFD<Ph_pt>:AUTO <Boolean>
Defines whether the SFD tool shall perform automatic impedance adjustments.
Suffix:
<Ph_pt>
.
This suffix is ignored.
Parameters:
<Boolean>
Manual operation: See "Adjust Impedance Mismatch" on page 601
SCPI Command Reference
