CALCulate<Ch>:TRANsform:VNETworks:SENDed:EMBedding<PhyPt>:
TNDefinition <CircuitModel>
Selects the circuit model for single ended port embedding.
Suffix:
<Ch>
.
Channel number
<PhyPt> Physical port number
Parameters:
<CircuitModel> FIMPort | CSL | LSC | CSC | LSL | SLC | SCL | SCC | SLL |
SHLC | GSL | LSG | GSG | SLG | SGL | SGG
Possible circuit models (character data); see Table 8-7
*RST: CSL
Example: See CALCulate<Ch>:TRANsform:VNETworks:SENDed:
EMBedding<PhyPt>[:STATe]
Manual operation: See "Network" on page 587
8.3.1.23 CALCulate:TTIMe:...
Defines the properties and retrieves the results of the rise time measurement provided
with the Extended Time Domain Analysis option R&S ZNB/ZNBT-K20.
CALCulate<Chn>:TTIMe:DATA? [<Data>]
Queries the results of the rise time measurement
Suffix:
<Chn>
.
Channel number used to identify the active trace
Query parameters:
<Data> ALL
If omitted, a single numeric value is returned. If ALL is specified,
the result consists of 6 numeric values. Furthermore, the inter-
pretation of the result values depends on the current trace's
stimulus axis (CALCulate<Chn>:TRANsform:TIME:XAXis).
See the table below.
Usage: Query only
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Extended Info" on page 655
<Data> omitted <Data> = ALL
Stimulus axis:
time
<rise time> <rise time>,<rise distance>, <start threshold crossing time>,
<start threshold crossing voltage>, <stop threshold crossing
time>, <stop threshold crossing voltage>
Stimulus axis:
distance
<rise distance> <rise distance>, <rise time>,<start threshold crossing dis-
tance>, <start threshold crossing voltage>, <stop threshold
crossing distance>, <stop threshold crossing voltage>
